Tango TX1 Gas Detector [Industrial Scientific] $271.35

Tango TX1 Gas Detector [Industrial Scientific]

$271.35

The Tango® TX1, with a 2-year run time and DualSense® Technology, increases worker safety, regardless of bump test frequency, while reducing overall costs.

DualSense Technology increases worker safety by using two
sensors to detect the same gas
Guaranteed for Life™ with replaceable sensors and batteries that
extend the life of the instrument
Optional AlarmAmp™ increases audible alarms to 110dB
Acknowledgeable gas alerts

Detailed Description
Specifications

By wearing the Tango® TX1 Portable gas detector, your workers will be the safest single gas monitor users in the world. A 2-year run time and patented DualSense Technology increase worker safety, regardless of bump test frequency, while reducing overall costs.
- Significantly increases worker safety - DualSense Technology ensures that, regardless of your current bump test policy, you will be significantly safer with the Tango than with any other single gas instrument on the market today. ^*
- Longer battery life - Operates continuously in an "always-on" mode for two years. After the battery can no longer support instrument life, it can be replaced for another two years of continuous operation.
- Louder instrument alarm - Alarms at 100dB at 10 centimeters making it twice the volume of Industrial Scientific's GasBadge units and louder than any single gas instrument on the market. Alarm volume can be increased by about 10dB for higher-noise environments with the addition of the optional AlarmAmp™.
^{*Based on iNet® data including more than 2 million bump tests and 100,000 unique sensors.}

SPECIFICATIONS

INSTRUMENT WARRANTY:

Guaranteed for Life™. Warranted for as long as the instrument is supported by Industrial Scientific Corporation (excludes sensors, batteries, and filters). CO and H2S sensors are warranted for 3 years. All other sensors are warranted for 2 years.

DISPLAY:

Segment liquid crystal display (LCD)

KEYPAD:

Two buttons

CASE MATERIALS:

Case top: Polycarbonate with a protective rubber overmold

Case bottom: Conductive polycarbonate

ALARMS:

Three strobe-emitting visual alarm LEDs (two red; one blue);

100 decibel (dB) audible alarm at a distance of 10 cm (3.94"); Vibration alarm

DIMENSIONS:

99 x 51 x 35 mm (3.9" x 2.0" x 1.4")

WEIGHT:

126.0 g (4.4 oz.)

TEMPERATURE RANGE:

-40°C to +50°C (-40°F to +122°F)

HUMIDITY RANGE:

15%-95% Non-condensing (continuous)

SENSORS:

CO, CO/H2, H2S, NO2, SO2 - Electrochemical sensor technology

SENSOR MEASURING RANGES:

Carbon Monoxide (CO): 1 to 1,000 ppm in 1 ppm increments

Carbon Monoxide (CO/H2 low): 0.0 to 1,000.0 ppm in 1 ppm increments

Hydrogen Sulfide (H2S): 0.0 to 500.0 ppm in 0.1 ppm increments

Nitrogen Dioxide (NO2): 0.0 to 150.0 ppm in 0.1 ppm increments

Sulfur Dioxide (SO2): 0.0 to 150.0 ppm in 0.1 ppm increments

BATTERY:

3.6 V Primary lithium-thionyl chloride (Li-SOCl2); 1.5AH, 2/3AA; replaceable;
non rechargeable; always on; up to 2-year run time depending on operating conditions

DATA LOGGING:

3 months at 10-second intervals

EVENT LOGGING:

60 alarm events

CERTIFICATIONS

INGRESS PROTECTION:

IP66; IP67

-40°C TO +50°C (-40°F TO +122°F)

ATEX	Ex ia I Ma; Ex ia IIC T4 Ga; Equipment Group and Category: I M1 and II 1G
CSA	Class I, Groups A B C D T4; Ex ia IIC T4
IECEx	Ex ia I Ma; Ex ia IIC T4 Ga
UL (C-US)	Class I, Groups A B C D T4; Class II, Groups E F G; Class I, Zone 0, AEx ia IIC T4
INMETRO	Ex ia I Ma; Ex ia IIC T4 Ga

-20°C TO +50°C (-4°F TO +122°F)

China Ex	Ex ia IIC T4 Ga
CMA	Ex ia I Ma; H2S, CO
KC	Ex ia IIC T4
EAC	PO Ex ia I X; 0 Ex iX IIC T4 X

These specifications are based on performance averages and may vary by instrument.

Resources:

Product Manual Literature Statement of Conformity

T40 Rattler Gas Detector [Industrial Scientific] $271.35

T40 Rattler Gas Detector [Industrial Scientific]

$271.35

The T40 Rattler™ is a low-cost, maintenance-free single-gas detector designed to protect personnel from dangerous hydrogen sulfide or carbon monoxide gas exposure in the most extreme conditions.

Low-cost CO or H2S monitoring
Peak/hold feature
1,500 hour run time on 1x AA alkaline battery
Compact size and lightweight

Detailed Description
Specifications
Part Numbers

The T40 Rattler™ is a low-cost, maintenance-free single gas monitor designed to protect personnel from dangerous hydrogen sulfide or carbon monoxide gas exposure in the most extreme conditions. Despite its compact size, the T40 Rattler includes features usually found only in larger multi-gas monitors including a large, liquid crystal display (LCD), internal vibrating alarm, audible/visual alarms and simple push-button operation.

The monitor continuously displays ambient carbon monoxide or hydrogen sulfide readings in PPM and will alert the user when gas concentrations exceed the preset low or high levels. Added features include adjustable alarm setpoints, calibration gas values, and choice of text-only display selected by the user through a simple, push-button routine. The T40 Rattler also has a peak/hold feature to show the highest reading during a shift and includes a patented flip-cap calibration adapter for quick and simple calibration. The T40 Rattler operates for up to 1,500 hours on a single “AA” battery (included) and is covered by a two-year warranty from the date of manufacture.

Case:

High visibility, impact-resistant composite with radio frequency interference (RFI) protection.

Dimensions:

3.375" x 2.3" x .75" (86 mm x 58 mm x 19 mm)

Weight:

3.5 ounces (98 grams)

Sensors:

CO, H ₂ S - Electrochemical

Measuring Ranges:

Gas	Symbol	Range	Increments
Carbon Monoxide	CO	0-999 ppm	1 ppm
Hydrogen Sulfide	H ₂ S	0-500 ppm	1 ppm

Power Source(Run Time):

Replaceable "AA" alkaline battery (approx. 1,500 hours typical)

Temperature Range:

-4°F to 122°F (-20°C to 50°C) typical

Humidity Range:

15 to 95% RH typical

Alarms:

Adjustable low and high alarm setpoints

Approvals:

UL and cUL - Class I, Groups A, B, C, D
CSA - Class I, Groups A, B, C, D
CENELEC (ATEX) and Australia - EEx ia IIC T4

Part Number	Description
18105247	T40 Rattler - Hydrogen Sulfide (alarms @ 10/20 ppm)
18105254	T40 Rattler - Carbon Monoxide (alarms @ 35/70 PPM)
18105874	T40 Nylon Carrying Case

Resources:

Product Manual Literature Statement of Conformity
