Ventis MX4 Multi-Gas Detector [Industrial Scientific]
$1,026.00
When you need a 4-gas monitor that will adapt to meet your needs, Ventis® MX4 is there. The lightweight instrument offers the portability and size of a single-gas instrument while delivering multi-gas protection. Use the incredibly configurable Ventis MX4 with a DSXi Docking Station to unlock the management tools found only in Industrial Scientific’s iNet® Control software. Ventis MX4 adapts to meet your needs.
- Monitors 1-4 gases
- Configured with or without a pump
- Available with a black or safety orange overmolded case
- iNet Ready and DSX Docking Station compatible
- Compatible with the Ventis Slide-on pump
Note: These units are spec'd with the standard 4-gas configuration:
- LEL(Pentane)
- H2S
- CO
- O2
If you have specific sensor needs, contact us at the office and let us work with you to build your perfect monitoring solution!
![Tango TX1 Gas Detector [Industrial Scientific]](http://cdn.shopify.com/s/files/1/0287/1766/products/tangoTX1_grande.jpg?v=1526417835)
![Tango TX1 Gas Detector [Industrial Scientific]](http://cdn.shopify.com/s/files/1/0287/1766/products/tangoTX1.jpg?v=1526417835)
Tango TX1 Gas Detector [Industrial Scientific]
$271.35
The Tango® TX1, with a 2-year run time and DualSense® Technology, increases worker safety, regardless of bump test frequency, while reducing overall costs.
-
DualSense Technology increases worker safety by using two
sensors to detect the same gas - Guaranteed for Life™ with replaceable sensors and batteries that
extend the life of the instrument - Optional AlarmAmp™ increases audible alarms to 110dB
- Acknowledgeable gas alerts
-
By wearing the Tango® TX1 Portable gas detector, your workers will be the safest single gas monitor users in the world. A 2-year run time and patented DualSense Technology increase worker safety, regardless of bump test frequency, while reducing overall costs.
- Significantly increases worker safety - DualSense Technology ensures that, regardless of your current bump test policy, you will be significantly safer with the Tango than with any other single gas instrument on the market today. *
- Longer battery life - Operates continuously in an "always-on" mode for two years. After the battery can no longer support instrument life, it can be replaced for another two years of continuous operation.
- Louder instrument alarm - Alarms at 100dB at 10 centimeters making it twice the volume of Industrial Scientific's GasBadge units and louder than any single gas instrument on the market. Alarm volume can be increased by about 10dB for higher-noise environments with the addition of the optional AlarmAmp™.
*Based on iNet® data including more than 2 million bump tests and 100,000 unique sensors.
-
SPECIFICATIONS
INSTRUMENT WARRANTY:
Guaranteed for Life™. Warranted for as long as the instrument is supported by Industrial Scientific Corporation (excludes sensors, batteries, and filters). CO and H2S sensors are warranted for 3 years. All other sensors are warranted for 2 years.
DISPLAY:
Segment liquid crystal display (LCD)
KEYPAD:
Two buttons
CASE MATERIALS:
Case top: Polycarbonate with a protective rubber overmold
Case bottom: Conductive polycarbonate
ALARMS:
Three strobe-emitting visual alarm LEDs (two red; one blue);
100 decibel (dB) audible alarm at a distance of 10 cm (3.94"); Vibration alarm
DIMENSIONS:
99 x 51 x 35 mm (3.9" x 2.0" x 1.4")
WEIGHT:
126.0 g (4.4 oz.)
TEMPERATURE RANGE:
-40°C to +50°C (-40°F to
+122 °F)HUMIDITY RANGE:
15%-95% Non-condensing (continuous)
SENSORS:
CO, CO/H2, H2S, NO2, SO2 - Electrochemical sensor technology
SENSOR MEASURING RANGES:
Carbon Monoxide (CO): 1 to 1,000 ppm in 1 ppm increments
Carbon Monoxide (CO/H2 low): 0.0 to 1,000.0 ppm in 1 ppm increments
Hydrogen Sulfide (H2S): 0.0 to 500.0 ppm in 0.1 ppm increments
Nitrogen Dioxide (NO2): 0.0 to 150.0 ppm in 0.1 ppm increments
Sulfur Dioxide (SO2): 0.0 to 150.0 ppm in 0.1 ppm increments
BATTERY:
3.6 V Primary lithium-thionyl chloride (Li-SOCl2); 1.5AH, 2/3AA; replaceable;
non rechargeable; always on; up to 2-year run time depending on operating conditionsDATA LOGGING:
3 months at 10-second intervals
EVENT LOGGING:
60 alarm events
CERTIFICATIONS
INGRESS PROTECTION:
IP66; IP67
-40°C TO +50°C (-40°F TO
+122 °F)ATEX
Ex ia I Ma; Ex ia IIC T4 Ga;
Equipment Group and Category: I M1 and II 1G
CSA
Class I, Groups A B C D T4; Ex ia IIC T4
IECEx
Ex ia I Ma; Ex ia IIC T4 Ga
UL (C-US)
Class I, Groups A B C D T4; Class II, Groups E F G;
Class I, Zone 0, AEx ia IIC T4
INMETRO
Ex ia I Ma; Ex ia IIC T4 Ga
-20°C TO +50°C (-4°F TO
+122 °F)China Ex
Ex ia IIC T4 Ga
CMA
Ex ia I Ma; H2S, CO
KC
Ex ia IIC T4
EAC
PO Ex ia I X; 0 Ex iX IIC T4 X
These specifications are based on performance averages and may vary by instrument.
![T40 Rattler Gas Detector [Industrial Scientific]](http://cdn.shopify.com/s/files/1/0287/1766/products/T40rattler_LR_grande.jpg?v=1526408450)
![T40 Rattler Gas Detector [Industrial Scientific]](http://cdn.shopify.com/s/files/1/0287/1766/products/T40rattler_LR.jpg?v=1526408450)
T40 Rattler Gas Detector [Industrial Scientific]
$271.35
The T40 Rattler™ is a low-cost, maintenance-free single-gas detector designed to protect personnel from dangerous hydrogen sulfide or carbon monoxide gas exposure in the most extreme conditions.
- Low-cost CO or H2S monitoring
- Peak/hold feature
- 1,500 hour run time on 1x AA alkaline battery
- Compact size and lightweight
-
The T40 Rattler™ is a low-cost, maintenance-free single gas monitor designed to protect personnel from dangerous hydrogen sulfide or carbon monoxide gas exposure in the most extreme conditions. Despite its compact size, the T40 Rattler includes features usually found only in larger multi-gas monitors including a large, liquid crystal display (LCD), internal vibrating alarm, audible/visual alarms and simple push-button operation.
The monitor continuously displays ambient carbon monoxide or hydrogen sulfide readings in PPM and will alert the user when gas concentrations exceed the preset low or high levels. Added features include adjustable alarm setpoints, calibration gas values, and choice of text-only display selected by the user through a simple, push-button routine. The T40 Rattler also has a peak/hold feature to show the highest reading during a shift and includes a patented flip-cap calibration adapter for quick and simple calibration. The T40 Rattler operates for up to 1,500 hours on a single “AA” battery (included) and is covered by a two-year warranty from the date of manufacture.
-
Case: High visibility, impact-resistant composite with radio frequency interference (RFI) protection. Dimensions: 3.375" x 2.3" x .75" (86 mm x 58 mm x 19 mm) Weight: 3.5 ounces (98 grams) Sensors: CO, H 2 S - Electrochemical Measuring Ranges:GasSymbolRangeIncrementsCarbon Monoxide CO 0-999 ppm 1 ppm Hydrogen Sulfide H 2 S 0-500 ppm 1 ppm Power Source(Run Time): Replaceable "AA" alkaline battery (approx. 1,500 hours typical) Temperature Range: -4°F to 122°F (-20°C to 50°C) typical Humidity Range: 15 to 95% RH typical Alarms: Adjustable low and high alarm setpoints Approvals: UL and cUL - Class I, Groups A, B, C, D
CSA - Class I, Groups A, B, C, D
CENELEC (ATEX) and Australia - EEx ia IIC T4 -
Part NumberDescription
18105247 T40 Rattler - Hydrogen Sulfide (alarms @ 10/20 ppm)18105254 T40 Rattler - Carbon Monoxide (alarms @ 35/70 PPM)18105874 T40 Nylon Carrying Case
