Pulleys

1.2 in. CR Single Pulley - SMC

$19.37

This SMC 1.2-inch single pulley is the mini of minis. Efficient and lightweight, its solid strength and efficiency tests to greater strengths than other pulleys in the same size and price range.

It has the required prusik minding capability for use in a haul system. A 1.20 in nylon sheave and zinc-coated axle make any system run smoothly.Simple to use and easy to carry into the field. Max Rope diameter for the CR is 13 mm. The CR pulley is a single pulley.

Simple to use and easy to carry into the field; max rope diameter for the CR is 13 mm.

Key Features:

• Nylon sheave
• Precision machined aluminum side plates
• Zinc coated axle
• Rotating side plates

Specifications:

• Height: 1.07 in (2.7 cm)
• Width: 1.75 in (4.4 cm)
• Length: 2.84 in (7.2 cm)
• Weight: 2.1 oz (59 g)
• MBS: 22 kN (5000 lbf)
• Tread: 0.83 in
• Axle: Nylon Bushing
• Sheave Material: Nylon
• Sheave: 1.20 in
• Max Rope Size: 13 mm

1.2 in. JR Double Pulley - SMC

$47.20

The JR and JRB pulleys are double pulleys with a max rope diameter for of 9 mm.

Key Features:

• Nylon sheave
• Precision machined aluminum side plates
• Zinc coated axle
• Rotating side plates
• JRB becket MBS: 2,298 lbf (13 kN)

Specifications:

• Color: Blue/Black
• Type: Double Pulley
• MBS: 22 kN (5000 lbf)
• Weight: 3.3 oz (94 g)
• Length: 3.57" (9.1 cm)
• Width: 1.75" (4.4 cm)
• Height: 1.56" (4.0 cm)
• Becket Strength: 13 kN
• Axle: Zinc Coated
• Sheave: 1.20" Nylon
• Tread: 0.83"
• Max Rope Size: 9 mm
• Material: Aluminum

1.2 in. TR Single Pulley - SMC

$49.64

The TR Pulley is strong, reliable compact, and lightweight. It is reasonably priced but doesn't sacrifice efficiency. Great performance for its size and cost. The TR Pulley has a true Oilite Bearing on a zinc coated axle for reliable performance.

Key Features:

• Lightweight aluminum
• 1.20 in Aluminum sheave
• Oilite bearings
• Accepts ropes up to 1/2 in

Specifications:

• Color: Green/Grey
• Type: Single Pulley
• MBS: 26 kN (5845 lbf)
• Weight: 2.3 oz (66 g)
• Length: 3.00" (7.6 cm)
• Width: 1.75" (4.4 cm)
• Height: 1.07" (2.7 cm)
• Axle: Oilite
• Sheave: 1.20" Aluminum
• Tread: 0.83"
• Max Rope Size: 13 mm
• Material: Aluminum

2 in. Swiftwater Pulley, Aluminum - SMC

$60.39

Noting the unique requirements found in Swift Water Rescue, we created an entirely new pulley to address those needs. The Swiftwater Rescue Pulley represents a reasonably priced, non-NFPA alternative to other midsized pulleys.

Made using high quality aluminum, this lightweight pulley weighs 6 oz. and features a 2‰۪‰۪ sheave. Anodized side plates feature a series of holes that help to minimize the hydroplaning effect that might occur with a typical pulley. These side plates are also configured to work as a Prusik Minding Pulley and are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.

High quality sealed ball bearings help to provide the optimal efficiency that is so crucial in rope rescue systems. They help to reduce the performance-robbing resistance that is inherent in most multiple component systems and are not prone to failure under misaligned loads or with twisted gear that may occur with needle bearings.

The wide and flat base maximizes the effectiveness of a Prusik hitch while a unique side plate formation allows the use of larger ropes in a compact pulley. The top hole accepts 2 large rescue carabiners or multiple small carabiners and allows the carabiners to be rotated freely and completely even while closed.

• Key Features
• Specifications

• • Lightweight aluminum
  • 2" Aluminum sheave
  • Sealed bearings
  • Accepts ropes up to 1/2"
• • Colour: Red
  • Type: Single Pulley
  • MBS: 34 kN (7786 lbf)
  • Weight: 6.0 oz (170 g)
  • Length: 4.00" (10.2 cm)
  • Width: 3.00" (7.6 cm)
  • Height: 1.37" (3.5 cm)
  • Axle: Ball Bearing
  • Sheave: 2.00" Aluminum
  • Max Rope Size: 13 mm
  • Material: Aluminum
  • Certification: UIAA

3 in. Double Prusik Minding Pulley - NFPA, SMC

$186.67

The unique shape of SMC's aluminum side plates allows the efficient use of prusik hitches as a belay or progress capture device. Constructed with a 3-inch diameter sheave running on a high-efficiency ball bearing. Low profile fasteners help eliminate the possibility of the pulley snagging. Pulley will accommodate up to 13 mm rope.

åÊ

• Key Features
• Specifications

• • UL certified to NFPA 1983 ‰ÛÏG‰۝ General Use.
  • High efficiency sealed ball bearings providing flawless function under conditions that would shut down lesser grade pulleys.
  • Side plates are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.
  • Oversized top hole is designed for use with up to 2 rescue carabiners and is large enough to allow sleeve of locked carabiner to pass through.
  • Low profile fasteners reduce snagging and hanging up when pulley is being moved.
  • Wide base design works most efficiently with Prusik cords of up to 8mm.
  • Made in the USA.
• • Colour: Gold/Grey
  • Type: Double Pulley
  • MBS: 48 kN (10790 lbf)
  • Weight: 1 lbs 4.8 oz (590 g)
  • Length: 7.10" (18.0 cm)
  • Width: 4.17" (10.6 cm)
  • Height: 2.20" (5.6 cm)
  • Becket Strength: 30 kN
  • Axle: Ball Bearing
  • Sheave: 2.97" Aluminum
  • Tread: 2.46"
  • Max Rope Size: 13 mm
  • Material: Aluminum

åÊ

3 in. Single Prusik Minding Pulley - NFPA, SMC

$124.90

The unique shape of SMC's aluminum side plates allow the efficient use of prusik hitches as a belay or progress capture device. Constructed with a 3-inch diameter sheave running on a high-efficiency ball bearing. Low profile fasteners help eliminate the possibility of the pulley snagging. Pulley will accommodate up to 13 mm rope.

• Features
• Specifications

• • Designed for 11 mm to 13 mm ropes
  • UL certified to NFPA 1983 “G” General Use.
  • High efficiency sealed ball bearings providing flawless function under conditions that would shut down lesser grade pulleys.
  • Side plates are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.
  • Oversized top hole is designed for use with up to 2 rescue carabiners and is large enough to allow sleeve of locked carabiner to pass through.
  • Low profile fasteners reduce snagging and hanging up when pulley is being moved.
  • Wide base design works most efficiently with Prusik cords of up to 8mm.
  • Made in the USA
• • Color: Red
  • Type: Single Pulley
  • MBS: 38 kN (8542 lbf)
  • Weight: 12.5 oz (354 g)
  • Length: 5.85" (14.9 cm)
  • Width: 4.17" (10.6 cm)
  • Height: 1.38" (3.5 cm)
  • Axle: Ball Bearing
  • Sheave: 2.97" Aluminum
  • Tread: 2.46"
  • Max Rope Size: 13 mm
  • Material: Aluminum

Aztek Pulley Set (2 Pulleys, 1 Pin, 1 Cover) - Rock Exotica

Sold Out - $297.69 $297.69

For those that want to use their own cordage and prusiks, these kits contain just the hardware from our best-selling Aztek Pulley Kits.

• 2 x Double Aztek MA pulleys
• 1 x Aztek Quick Release Pin
• 1 x Pulley Cover

Double Prusik Minding Pulley - NFPA, SMC

$142.01

The 2‰۝ Double PMP "Prusik Minding Pulley" represents a mid-sized option for those needing the unique features of a PMP while limited for size.

This pulley is one of the lightest UL Certified pulleys meeting NFPA ‰ÛÏG‰۝ General Use.

Prusik Minding Pulleys are especially versatile and may be used in many ways, from progress capture and hauling systems to crevasse rescue, high-lines and Tyrolean traverses.

The wide base design maximizes the effectiveness of a Prusik hitch while a unique side plate formation allows the use of larger ropes in a compact pulley ideally suited for 8mm prusik.

An oversized bell-shaped top hole accepts 2 large rescue carabiners or multiple small carabiners and allows the carabiners to be rotated freely and completely. Sealed ball bearings provide optimal efficiency and reduce the performance-robbing resistance that is inherent in most multiple component systems. In addition, sealed ball bearings are not prone to failure under misaligned loads or with twisted gear as can be the case with needle bearings.

Solid side plates help prevent foreign object access and reduce snagging and are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.

åÊ

• Features
• Specifications

• • UL certified to NFPA 1983 å?ÛÏG‰۝ General Use.
  • High efficiency sealed ball bearings providing flawless function under conditions that would shut down lesser grade pulleys.
  • Side plates are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.
  • Oversized top hole is designed for use with up to 2 rescue carabiners and is large enough to allow sleeve of locked carabiner to pass through.
  • Low profile fasteners reduce snagging and hanging up when pulley is being moved.
  • Wide base design works most efficiently with Prusik cords of up to 8mm.
  • Made in the USA
• • Model #: NFPA152800
  • Type: Double
  • Axle: Ball Bearing
  • Material: High Quality Aluminum
  • Dimensions: 5.1‰۝ x 2.9‰۝ x 2.2‰۝
  • Weight: 10.4 oz (295g)
  • Max. Rope: 1/2‰۝ (13mm)
  • Sheave: 2‰۝ aluminum
  • 3 Sigma MBS: 46kN (10,341 lbf)
  • Becket Strength: 23kN (5,170 lbf)
  • NFPA1983 Certified
  • Made In USA

Double Prusik Minding Pulley, Aluminum - Rock Exotica

$138.58

Rock Exotica has reinvented the machined pulley. Their machined pulleys are milled from solid 7075 aluminum, which allows material to be removed where it's not needed and left it where it is. The axle is machined as part of the side plate, allowing for a flush head axle screw. That's why these pulleys are more compact, stronger and lighter weight than conventional stamped pulleys.

Double Prusik Minding Pulley, Micro (1 3/8 in.) - NFPA, SMC

Sold Out - $117.49

Just the thing for smaller ropes and lighter loads, SMC's Micro PMP's are ideal for building a mini haul rig or anywhere that a compact lightweight system is needed. Double version is designed with a becket to accommodate compound and complex pulley systems. Max rope diameter 13 mm.

Double Stainless Steel Pulley - NFPA, SMC/RA

Sold Out - $113.44

Based on Russ Anderson's original design, these pulleys are essential equipment for the serious rigger. Rotating side plates allow attachment of the pulley anywhere on the rope and the 3 inch and 4 inch models will accept multiple carabiners. Axle nuts are marked with a blue witness line to indicate if the axle nut has been turned or tampered with.

Double Swivel Pulley - NFPA, CMC

$228.50

This Prusik-minding pulley (PMP) is ideal for high anchor points or tripod use. The rotating swivel aligns the rope with the direction of the pull and the double swivel pulley features aluminum sheaves and a becket.  By combining the swivel with the pulley, overall system length is minimized, increasing travel distance.

The patented pivoting side plates allow the rope to be quickly inserted or removed without removing the pulley from the connection point.

Product Features:

• Prusik-minding side plates open without having to disconnect the pulley from the anchor
• A double-detent button prevents accidental opening of side plate
• Sealed ball bearings provide maximum efficiency
• Certification: NFPA - General Use
• MBS: 44KN

KOOTENAY Pulley - Petzl

$256.37

KOOTENAY Knot-passing pulley. Voluminous rope channel allows the passage of joining knots (lifting loads over great distances or moving along a Tyrolean traverse with two ropes). Large diameter sheave mounted on sealed ball bearings for excellent efficiency. Locking pins on the sheave allow use of the pulley as an anchor. Height: 260 mm

MINDER Prusik Minding Pulley - Petzl

$87.04

MINDER High strength, high efficiency Prusik pulley. Special side plates designed for use with a Prusik friction hitch in progress capture systems. Large diameter sheave mounted on sealed ball bearings for excellent efficiency. Accepts up to three carabiners to facilitate use.

Omni-Block Swivel Pulley, Double - Rock Exotica

$178.87

The Omni-Block combines a swivel and pulley into one tool, and incorporates a unique sideplate that opens while the pulley is still attached to the anchor. Traditionally, a pulley is connected to a swivel by a carabiner. However, the Omni eliminates the need for the carabiner, reducing length and pieces of equipment in the rigging system. The short length of the Omni is important when used in high-angle, confined space or other space-sensitive rigging environments. The reduced weight of the Omni will make hauling your gear easier. Additionally the Omni sideplate can be opened without detaching from the carabiner. Traditional pulleys require removing from the carabiner to change the rope. With the Omni, the user is able to do this while the pulley is still secured.

Features:

• Allows rope change without detachment from carabiner
• The integrated swivel top allows the pulley to orient as needed in response to the load.
• Pulley body is machined from a solid block of aluminum for strength optimization and weight reduction.
• Shortens the length of rigging by combining the pulley and swivel in one device.

Specifications:

• Sheave size:í« 1.5" (38mm)
• Material: Aluminum
• Weight: 14.5oz (411gm)
• MBS: 36kN
• WLL: 8kN
• Max rope diameter: 1/2" (13mm)
• Certifications: CE / UIAA

Omni-Block Swivel Pulley, Single - Rock Exotica

$109.67

The Omni-Block combines a swivel and pulley into one tool, and incorporates a unique sideplate that opens while the pulley is still attached to the anchor. Traditionally, a pulley is connected to a swivel by a carabiner. However, the Omni eliminates the need for the carabiner, reducing length and pieces of equipment in the rigging system. The short length of the Omni is important when used in high-angle, confined space or other space-sensitive rigging environments. The reduced weight of the Omni will make hauling your gear easier. Additionally the Omni sideplate can be opened without detaching from the carabiner. Traditional pulleys require removing from the carabiner to change the rope. With the Omni, the user is able to do this while the pulley is still secured.

Features:

• Allows rope change without detachment from carabiner
• The integrated swivel top allows the pulley to orient as needed in response to the load.
• Pulley body is machined from a solid block of aluminum for strength optimization and weight reduction.
• Shortens the length of rigging by combining the pulley and swivel in one device.

Personal Single Rescue Pulley - NFPA, Burgundy, CMC

$100.58

This lightweight, full-strength, Prusik-minding pulley is ideal for mountain rescue, swiftwater, or other technical teams where equipment weight is a significant consideration.

By machining the side plates, the thickness of the metal can be varied to maximize the strength-to-weight ratio, a process that cannot be done with traditional bent metal side plates. Sealed ball bearings provide high efficiency and aluminum side plates protect the rope. An extremely low-profile stainless steel axle assembly reduces snagging on rocks, roots, and uneven surfaces.

Designed for lifelines up to 1/2 inch (13mm) in diameter.

ProTech Double Pulley - NFPA, Sand, CMC

$152.30

Ideal for mountain rescue, swiftwater, ski patrol, tower work or other technical uses, where equipment weight is a significant consideration, these lightweight, full-strength Prusik-minding pulleys feature extremely low-profile stainless steel hardware to reduce snagging on rocks, roots, and uneven surfaces. By machining the side plates, the thickness of the metal can be optimized to maximize the strength-to-weight ratio, a process that cannot be done with the raditional bent metal side plates. The unique axle assembly delivers a smooth side plate and impressive strength. The aluminum sheave is mounted on sealed ball bearings for high efficiency. Ideal for small block-and-tackle kits. Note: Not compatible with 1/2-in. (12.5-mm) or larger ropes.

Prusik Minding Single Swivel Pulley - NFPA, CMC

$208.34

The new Prusik-minding pulley (PMP) is ideal for high anchor points or tripod use. The rotating swivel aligns the rope with the direction of the pull. Its stainless steel sheave can be used with either rescue rope or wire cable. By combining the swivel with the pulley, overall system length is minimized, increasing travel. The patented pivoting side plate allows the rope to be quickly inserted.

Product Features:

• Stainless steel sheave allows use with wire cable
• Prusik-minding side plate opens without having to disconnect the pulley from the anchor
• A double-detent button prevents accidental opening of side plate
• Sealed ball bearings provide maximum efficiency

Roll-N-Lock - Ultralight Pulley and Rope Clamp[CT]

$113.26

Ultra-light pulley/rope clamp (80 g) designed for work, rope climbing maneuvers, rescue and self-rescue situations, manufactured by Climbing Technology.

Features

• For use with ropes EN 892 / EN 1891 Ø 8 ÷ 13 mm;
• Spring-operated cam for use as a rope ascender;
• Sliding lock for use as a pulley;
• It allows the hauling of light loads;
• Exceptional use with webbing 10÷16 mm, for positioning adjustment;
• Developed to work also on wet or dirty ropes.



Shuttle Tandem Cable Pulley- SMC

$104.30

The SMC Shuttle Tandem Pulley is one of the lightest, fastest, and most versatile tandem pulleys on the market. Designed to last the long haul and for use on cable or rope up to 13 mm. The SMC Shuttle features stainless steel sheaves, four independent sealed ball bearing assemblies, stainless steel fasteners, and multiple connection points with enough room for rescue carabiners.

Single Prusik Minding Pulley - NFPA, SMC

$91.00

The 2” Single PMP "Prusik Minding Pulley" represents a mid-sized option for those needing the unique features of a PMP.

This mid-sized PMP is the perfect choice for rigging with 11 mm (7/16 inch) rope or when you don't have room for a 3 inch PMP. Pulley will accommodate up to 13 mm rope.

This pulley is one of the lightest UL Certified pulleys meeting NFPA “G” General Use. In fact, the breaking strength for this pulley is the highest available based upon the strength to weight ratio. Prusik Minding Pulleys are especially versatile and may be used in many ways, from progress capture and hauling systems to crevasse rescue, high-lines and Tyrolean traverses.

The wide base design maximizes the effectiveness of a Prusik hitch while a unique side plate formation allows the use of larger ropes in a compact pulley ideally suited for 8mm prusik. An oversized bell-shaped top hole accepts 2 large rescue carabiners or multiple small carabiners and allows the carabiners to be rotated freely and completely. Sealed ball bearings provide optimal efficiency and reduce the performance-robbing resistance that is inherent in most multiple component systems. In addition, sealed ball bearings are not prone to failure under misaligned loads or with twisted gear as can be the case with needle bearings.

Solid side plates help prevent foreign object access and reduce snagging and are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.

• Features
• Specifications

• • UL certified to NFPA 1983 “G” General Use.
  • High efficiency sealed ball bearings providing flawless function under conditions that would shut down lesser grade pulleys.
  • Side plates are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.
  • Oversized top hole is designed for use with up to 2 rescue carabiners and is large enough to allow sleeve of locked carabiner to pass through.
  • Low profile fasteners reduce snagging and hanging up when pulley is being moved.
  • Wide base design works most efficiently with Prusik cords of up to 8mm.
  • Made in the USA
• • Model #: NFPA152700
  • Type: Single
  • Axle: Ball Bearing
  • Material: High Quality Aluminum
  • Dimensions: 3.97” x 2.9” x 1.37”
  • Weight: 6.3 oz (179g)
  • Max. Rope: 1/2” (13mm)
  • Sheave: 2” aluminum
  • 3 Sigma MBS: 36kN (8,093 lbf)
  • NFPA1983 Certified
  • Made In USA

Single Prusik Minding Pulley, Aluminum - Rock Exotica

$83.56

Rock Exotica has reinvented the machined pulley. Their machined pulleys are milled from solid 7075 aluminum, which allows any̴Ì_material to be removed from where it's not needed and left it where it is required. The axle is machined as part of the side plate, allowing for a flush head axle screw. That's why these pulleys are more compact, stronger and lighter weight than conventional stamped pulleys.

Single Prusik Minding Pulley, Micro (1 3/8 in.) - NFPA, SMC

$60.67

The SMC Micro PMP‰۪s areåÊa well-built, small pulley that has plenty of capacity.

These pulleys are designed and manufactured to the same high-quality standards as the full-sized PMP‰۪s.

The wide base design maximizes the effectiveness of a Prusik hitch while a unique side plate formation allows the use of larger ropes in a compact pulley.

An oversized bell-shaped top hole accepts a large rescue carabiner or multiple small carabiners. The single can be rigged with 2 carabiners in a way that the 2nd carabiner serves as a Becket.

Solid side plates help prevent foreign object access and reduce snagging and are precisely tensioned for easy one-handed operation and secure placement at any point along the rope.

Sealed ball bearings provide optimal efficiency and reduce the performance-robbing resistance that is inherent in most multiple component systems and are not prone to failure under misaligned loads or with twisted gear that may occur with needle bearings.

åÊ

• Features
• Specifications

• • UL certified to NFPA 1983 ‰ÛÏT‰۝ Technical Use as required by most government and private agencies.
  • Side plates are precisely tensioned and for easy one-handed operation and secure placement at any point along the rope.
  • Matched double-bend side plates help to eliminate compression under load and the resulting friction on rope or sheave.
  • Low profile fasteners help to reduce snagging and hanging up when the pulley is being moved.
  • Wide base design works most efficiently with Prusik cords of up to 8mm.
  • An over-sized top hole is designed for use with multiple carabiners. Single may be rigged with 2 carabiners in such a way that the 2nd carabiner may serve as a Becket.
  • Made in the USA.
• • Model #: NFPA153001
  • Type: Single
  • Dimensions: 3.75‰۝ x 2.55‰۝ x 1.12‰۝
  • Material: High-Quality Aluminum
  • Weight: 3.5 oz (99g)
  • Max. Rope: 1/2‰۝ (13mm)
  • Sheave: 1-3/8‰۝
  • 3 Sigma MBS: 4,946 lbf (22kN)
  • NFPA1983 (T) Certified
  • Made In USA
